Battery Chargers
27V thru 48V DLS Power
Converters/Battery Chargers provide quality service and protection for a
wide range of voltage applications. Each features the Dual Voltage Jack
for easy two-step charging, external and internal IQ controller option
compatibility, and are backed by our standard Two-Year Warranty.
|
Using state-of-the-art,
switch-mode technology, the DLS Power Supply series is engineered with the
user and variable environmental conditions in mind. Extra care has been
given to insure many years of service-free operation, even when subjected
to extremely harsh conditions. Batteries are charged quickly and
efficiently without over charging and pumps, motors, and fans operate
perfectly for prolonged life.
IOTA Engineering uses advanced switch mode technology to bring to market
highly sophisticated electronic converter/power supplies at appealing
affordability.
Exceptionally clean DC output insures pumps, motors, fans, and lights work
perfectly. This means longer life for any connected load; virtually no AC
ripple to cause static or premature failure of radio or television
equipment.
The DLS series converter/charger quickly and efficiently charges batteries
from the full rated output of the DLS. The DL S then maintains the
batteries, only putting into the battery what is required by load or self
discharge, cutting back to milliamps as the battery requires.
Low and transient AC line voltage is a major cause of converter/power
supply failure. The DLS series converter/power supply is protected against
low line voltage, as well as spikes coming from the AC power source or
from improperly adjusted generators.
The DLS series converter/power supply meets F.C.C. criteria, minimizing
radio and television equipment interference, especially on the lower
frequency bands.
The DLS series converter/power supply can be used with or without a
battery. When used as a converter/power supply, the DLS model will only
supply what is required by the load. When not in use it is essentially
off, reducing electricity usage.
Even in its subcompact size, the DLS series converter/power supply, at
full load, has an operating temperature half that of some switch mode
electronic models. This means substantially longer life and safer
operation.
Tight line-load regulation ensures that the output voltage holds steady
from no load to full load. This keeps pumps, motors, and lights working at
the correct voltage even during brown out situations.
Proportional Fan Circuitry provides an extra measure of protection. During
times of heavy load demands, the automatic circuitry will activate the fan
before thermal stress can occur on any internal components. Reliability
and durability is built into all DLS models.
In the event the batteries or the DLS unit is wired incorrectly, the DLS
converter/power supply is protected from damage. External fuses can be
quickly and easily replaced. |
12V DLS SERIES
POWER CONVERTER/BATTERY CHARGERS
These DLS AC/DC Power Converters are for use with 12VDC and
108-132VAC applications and operate at 13.6V for charging the
battery. Available amperages range from 90 to 15 amps. |
DLS-15
15
amp AC/DC power supply for 12V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
The DLS-15 features a Dual Voltage Jack which allows
switching from a long-term float voltage of 13.6vdc to a 14.2vdc
rapid charge by simply inserting the dual voltage plug (included)
into the jack.
The DLS-15 is also available with an
IQ
Smart-Controller already integrated into the unit, providing
"smart-charging" capability and increasing the performance of the
DLS. |
DLS-30
30
amp AC/DC power supply for 12V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-30 features a Dual Voltage Jack which allows
switching from a long-term float voltage of 13.6vdc to a 14.2vdc
rapid charge by simply inserting the dual voltage plug (included)
into the jack.
The DLS-30 is also available with an IQ Smart-Controller
already integrated into the unit, providing "smart-charging"
capability and increasing the performance of the DLS. |
DLS-45
45
amp AC/DC power supply for 12V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-45 features a Dual Voltage Jack which allows
switching from a long-term float voltage of 13.6vdc to a 14.2vdc
rapid charge by simply inserting the dual voltage plug (included)
into the jack.
The DLS-45 is also available with an IQ Smart-Controller
already integrated into the unit, providing "smart-charging"
capability and increasing the performance of the DLS. |
DLS-55
55
amp AC/DC power supply for 12V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-55 features a Dual Voltage Jack which allows
switching from a long-term float voltage of 13.6vdc to a 14.2vdc
rapid charge by simply inserting the dual voltage plug (included)
into the jack.
The DLS-55 is also available with an IQ Smart-Controller
already integrated into the unit, providing "smart-charging"
capability and increasing the performance of the DLS. |
DLS-75
75
amp AC/DC power supply for 12V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-75 features a Dual Voltage Jack which allows
switching from a long-term float voltage of 13.6vdc to a 14.2vdc
rapid charge by simply inserting the dual voltage plug (included)
into the jack.
The DLS-75 is also available with an IQ Smart-Controller
already integrated into the unit, providing "smart-charging"
capability and increasing the performance of the DLS. |
DLS-90
90
amp AC/DC power supply for 12V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-90 features a Dual Voltage Jack which allows
switching from a long-term float voltage of 13.6vdc to a 14.2vdc
rapid charge by simply inserting the dual voltage plug (included)
into the jack.
The DLS-90 is also available with an IQ Smart-Controller
already integrated into the unit, providing "smart-charging"
capability and increasing the performance of the DLS. |
24V DLS SERIES
POWER CONVERTER/
BATTERY CHARGERS
These DLS AC/DC Power Converters are for use with 24VDC and
108-132VAC systems and operate at 27.2V for charging the battery.
Available amperages range from 40 to 15 amps. |
DLS-27-15
15
amp AC/DC power supply for 24V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-27-15 features a Dual Voltage Jack which
allows switching from a long-term float voltage to a rapid charge by
simply inserting the dual voltage plug (included) into the jack.
The DLS-27-15 is also compatible with the IQ
Smart-Controller, providing "smart-charging" capability and
increasing the performance of the DLS. |
DLS-27-25
25
amp AC/DC power supply for 24V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-27-25 features a Dual Voltage Jack which
allows switching from a long-term float voltage to a rapid charge by
simply inserting the dual voltage plug (included) into the jack.
The DLS-27-25 is also compatible with the IQ
Smart-Controller, providing "smart-charging" capability and
increasing the performance of the DLS. |
DLS-27-40
40
amp AC/DC power supply for 24V systems
Features include:
Switch-Mode Technology
Low and Transient AC Line Voltage Protection
Exceptionally Clean DC Output
Reverse Polarity Protection
Proportional Fan Control
The DLS-27-40 features a Dual Voltage Jack which
allows switching from a long-term float voltage to a rapid charge by
simply inserting the dual voltage plug (included) into the jack.
The DLS-27-40 is also compatible with the IQ
Smart-Controller, providing "smart-charging" capability and
increasing the performance of the DLS. |
| 36V thru 48V DLS Power
Converters/Battery Chargers provide quality service and protection
for a wide range of voltage applications. Each features the Dual
Voltage Jack for easy two-step charging, external and internal IQ
controller option compatibility, and are backed by our standard
Two-Year Warranty. |
DLS 36-20
36 VOLT 20 AMP POWER CONVERTER / BATTERY CHARGER
The DLS 36-20 features a
Two-Step Voltage Jack which allows switching from a long-term float
voltage to an increased rapid charge by simply inserting the dual
voltage plug (included) into the jack.
The DLS 36-20 is also available with an IQ smart-controller
already integrated into the unit which converts the charger into a
3-stage "smart" charger, increasing the performance of your DLS
36-20.
|
DLS 42-18
42 VOLT 18 AMP POWER CONVERTER / BATTERY CHARGER
The DLS 42-18 features a
Two-Step Voltage Jack which allows switching from a long-term float
voltage to an increased rapid charge by simply inserting the dual
voltage plug (included) into the jack.
The DLS 42-18 is also available with an IQ smart-controller
already integrated into the unit which converts the charger into a
3-stage "smart" charger, increasing the performance of your DLS
42-18. |
DLS 48-15
48 VOLT 15 AMP POWER CONVERTER / BATTERY CHARGER
The DLS 48-15 features a
Two-Step Voltage Jack which allows switching from a long-term float
voltage to an increased rapid charge by simply inserting the dual
voltage plug (included) into the jack.
The DLS 48-15 is also available with an IQ smart-controller
already integrated into the unit which converts the charger into a
3-stage "smart" charger, increasing the performance of your DLS
48-15. |
DLS 48-20
48 VOLT 20 AMP POWER CONVERTER / BATTERY CHARGER
The DLS 48-20 features a Two-Step Voltage Jack which allows
switching from a long-term float voltage to an increased rapid
charge by simply inserting the dual voltage plug (included) into the
jack.
The DLS 48-20 is also available with an IQ smart-controller
already integrated into the unit which converts the charger into a
3-stage "smart" charger, increasing the performance of your DLS
48-20.
|
The IQ Smart Controller
offers automatic charging control for the DLS power
converters/chargers to provide longer and safer use of your system's
battery. The IQ Controller is compatible with any DLS model, and is
covered under our standard Two-Year Warranty.
The IQ Controller allows the DLS charger to operate as an automatic
3-stage "smart charger". This gives the customer the benefit of
Bulk, Absorption, and Float stage charging, increasing the charging
capacity of the DLS charger and decreasing charge times, insuring
proper and safe battery charging and minimizing over-charging. This
"smart" technology monitors the battery at all times. If the DLS
voltage remains in the long term float stage for more than 7 days,
the IQ will automatically deliver a boost charge for a predetermined
time, then automatically return to the normal float stage.
DLS power converters can be ordered with the IQ Controller option
internally integrated into the unit.
Bulk Charge
The batteries are charged from the full rated output of the DLS
charger. During this stage, the batteries are recharged quickly to
reduce charge times.
Absorption Charge
The batteries are then held in the absorption stage for a controlled
period, insuring a full and complete charge. During this stage, the
battery cells are equalized to 14.2vdc (for 12V systems) for
increased capacity.
Float Charge
During the float stage, the DLS charge voltage is reduced. This
minimizes gassing, while maintaining a full charge. If the battery
voltage drops below 12.6vdc (for 12V systems), the IQ Controller
will restart at the bulk charge stage and repeat this cycle.
Weekly Equalization
If the batteries have not received a "smart charge" during a 7 day
period, the IQ Controller will switch the DLS charger into a
pre-programmed, equalization stage to top off the batteries. This
ensures full batteries all of the time without over-charging.
|
|
|
|
Battery Chargers
Smart, Multistage Charging
Xantrex Truecharge multistage battery chargers and microprocessor controlled
for fast and accurate charging of all deep-cycle ‘house’ batteries. A wide AC
input voltage range enables proper delivery of a full three-stage charge, even
when charging from less than perfect shorepower or generator power. Smart
features, such as adjustable temperature compensation and independent settings
for flooded, gel and AGM batteries, prevent battery damage due to overcharging,
and also help extend the life of expensive batteries.
Truecharge 10
Portable 10 Amp Multistage Battery Charger
with Clip Leads
High
Performance, Light Duty Charging
Truecharge 10
(part#804-0100) is a 10-amp portable charger with an AC power cord and
clip leads for quick DC connection. Microprocessor- controlled for fast
and accurate charging of deep-cycle batteries, a wide AC input voltage
range enables proper delivery to a full three-stage charge – even when
charging from less than perfect quality shorepower or generator power.
Truecharge 10 is recommended for flooded and gel battery banks rated 200
amp hours or lower.
Product Features
10 amp output
Microprocessor controlled,
multistage charging
Easy battery connection with clip
leads
Supports charging for flooded or
gel lead-acid batteries
Wide voltage range operation (90
to 135 VAC, 50/60Hz)
Three settings for temperature
compensation
Automatic 21 day top-up
Lightweight, compact size
CSA/NRTLcertified to UL and CSA
standards
One year warranty
Protection Features
Over-temperature shutdown
Non-sparking battery connection
Transformer isolated for safety
and to protect against electrolysis
Reverse polarity protection
(internal fuse)
Short-circuit and surge
protection
|
True charge
10i
Portable 10 A Multistage Battery Charger with Clip Leads
High
Performance, Light Duty Charging
Truecharge 10i
(part#804-2100) is a 10-amp portable charger with an AC power cord and
clip leads for quick DC connection. Microprocessor-controlled for fast and
accurate charging of all deep-cycle ‘house’
batteries, a wide AC input
voltage range enables proper delivery to a full three-stage charge – even
when charging from less than perfect quality shorepower or generator
power.
Product
Features
-
10 amp
output
-
Microprocessor controlled, multistage charging
-
Easy battery
connection with clip leads
-
Supports
charging for flooded or gel lead-acid batteries
-
Wide voltage
range operation (200-250 VAC, 50/60 Hz)
-
Three
settings for temperature compensation
-
Automatic 21
day top-up
-
Lightweight,
compact size
-
One year
warranty
Protection
Features
Over-temperature shutdown
Non-sparking battery connection
Transformer isolated for safety and to protect against electrolysis
Reverse polarity
Short-circuit and surge protection
|
TRUECHARGE
10TB
Portable 10 Amp Multistage Battery Charger
Charges Two
Battery Banks Simultaneously
Truecharge
10TB (part#804-0111) is a 10-amp continuous duty charger with enclosed
screw terminals for safe, secure AC and DC connection. It features two
outputs that are isolated from one another
 for simultaneous charging of
two battery banks. One bank can be used for the engine, while the other
can be used to recharge the house bank - or two house bank batteries can
be recharged at the same time. Truecharge 10TB is also able to recharge
completely discharged batteries (when voltage approaches 0 VDC).
Product Features
-
10 amp
output
-
Microprocessor controlled, multistage charging
-
Charges up
to two battery banks simultaneously
-
Settings
for flooded or gel lead-acid batteries
-
Wide
voltage range operation (90–135 VAC, 50/60 Hz)
-
Automatic
21 day top-up
-
Covered
terminal block with screw terminals for safe and easy connection
-
CSA/NRTL
Certified to UL and CSA Standards
-
One year
warranty
Protection Features
-
Over-temperature shutdown and overload protection
-
Ignition
protected
-
Transformer isolated for safety and to protect against electrolysis
-
Reverse
polarity protection (15 A fuse on each DC output)
-
Short-circuit and surge protection
|
|
Truecharge
20+
20 Amp
Multistage Battery Charger
Charges
Three Battery Banks Simultaneously
With an
output of 20 amps, Truecharge 20+ is ideal for your deep cycle batteries
when recharging from a source between 90-135 VAC at
 60 Hz. Truecharge
20+ offers high frequency power conversion, microprocessor control,
multi-step charging, wide input voltage range, battery type selector
switch, and an extensive array of protection features.
Product
Features
-
20 amp
output
-
Microprocessor controlled, multistage charging
-
Charges up
to three battery banks simultaneously
-
Independent settings for AGM, flooded or gel lead-acid batteries
-
Wide
voltage range operation (90–135 VAC, 50/60 Hz)
-
Optional
remote LED panel to indicate battery and charge status
-
Automatic
21 day top-up
-
Durable
and corrosion resistant chassis
-
CSA/NRTL
certified to UL and CSA standards
-
One year
warranty
Protection Features
-
Over-temperature shutdown and overload projection
-
Adjustable
temperature sensitive charging for optimal battery charging
-
Transformer isolated for safety and to protect against electrolysis
-
Reverse
polarity protection (internal fuses open)
-
Short-circuit and surge protection
-
Ignition
protected
-
Equalization mode conditions batteries for longer life
Options
-
Battery
temperature sensor (part#808-0231)
-
Remote
display panel
(part#808-0200) – displays total charging current and battery voltage
for two battery banks using bar graph LEDs
|
|
Truecharge
20i
Charges
Two Battery Banks Simultaneously
Xantrex
Truecharge 20i (part#804-2270) is a microprocessor-controlled 2-bank,
multistage battery charger designed to charge your
deep-cycle batteries
safely and efficiently. The Truecharge 20i has limited DC ripple and
deliver the maximum charge rate from a wide voltage range.
Product
Features
-
20 amp DC
output
-
LED
display shows charge current and charger status
-
Microprocessor-controlled, multistage charging (bulk/absorption/float)
-
Dual-bank
charging with 2 separate DC positive terminals
-
Settings
for charging flooded (wet) and gel batteries
-
Wide AC
input voltage range operation
-
Optional
remote LED display panel
-
Automatic
21-day top-up
-
Temperature compensation via selector switch or optional automatic
temperature sensor
-
Durable
corrosion resistant chassis
-
Equalization mode
-
CE marked
-
One year
warranty
Protection Features
-
Over-temperature shutdown and overload protection
-
Non-sparking battery connection
-
Transformer isolated to protect against electrolysis
-
Reverse
polarity protection
-
Short-circuit and surge protection
Options
-
Remote
battery temperature sensor (part#808-0231)- automatically adjusts
charger output according to battery temperature
-
Remote
display panel (part#808-0220) - displays total charging current and
battery voltage
|
|
Truecharge
40+
40 Amp Multistage Battery Charger
Charges
Three Battery Banks Simultaneously
With an
output of 40 amps, Truecharge 40+ (part#804-0440) is ideal for your deep
cycle batteries when recharging from a source between 90-135 VAC at 60
Hz. Truecharge 40+ offers high frequency power
conversion,
microprocessor control, multi-step charging, wide input voltage range,
battery type selector switch, and an extensive array of protection
features.
Product Features
-
40 amp
output
-
Microprocessor controlled, multistage charging
-
Charges up
to three battery banks simultaneously
-
Independent settings for AGM, flooded or gel lead-acid batteries
-
Wide
voltage range operation (90–135 VAC, 50/60 Hz)
-
Optional
remote LED panel to indicate battery and charge status
-
Automatic
21 day top-up
-
Durable
and corrosion resistant chassis
-
CSA/NRTL
certified to UL and CSA standards
-
One year
warranty
Protection Features
-
Over-temperature shutdown and overload projection
-
Adjustable
temperature sensitive charging for optimal battery charging
-
Transformer isolated for safety and to protect against electrolysis
-
Reverse
polarity protection (internal fuses open)
-
Short-circuit and surge protection
-
Ignition
protected
-
Equalization mode conditions batteries for longer life
Options
-
Battery
temperature sensor (part#808-0231)
-
Remote
display panel
(part#808-0200)– displays total charging current and battery voltage
for two battery banks using bar graph LEDs
|
|
Truecharge
40i
Charges Two Battery Banks Simultaneously
Xantrex
Truecharge 40i (part#804-2470) is a microprocessor-controlled 2-bank,
multistage battery charger designed to charge your
deep-cycle batteries
safely and efficiently. The Truecharge 40i has limited DC ripple and
deliver the maximum charge rate from a wide voltage range.
Product Features
-
40 amp DC
output
-
LED
display shows charge current and charger status
-
Microprocessor-controlled, multistage charging (bulk/absorption/float)
-
Dual-bank
charging with 2 separate DC positive terminals
-
Settings
for charging flooded (wet) and gel batteries
-
Wide AC
input voltage range operation
-
Optional
remote LED display panel
-
Automatic
21-day top-up
-
Temperature compensation via selector switch or optional automatic
temperature sensor
-
Durable
corrosion resistant chassis
-
Equalization mode
-
CE marked
-
One year
warranty
Protection Features
-
Over-temperature shutdown and overload protection
-
Non-sparking battery connection
-
Transformer isolated to protect against electrolysis
-
Reverse
polarity protection
-
Short-circuit and surge protection
Options
-
Remote
battery temperature sensor (part# 808-0231) - automatically adjusts
charger output according to battery temperature
-
Remote
display panel (part# 808-0220)- displays total charging current and
battery voltage
|
Xantrex Truecharge battery chargers are available in 10 amp, 20 amp and 40
amp versions including the following:
 Note:
To view the above PDF documents, you will need the
free Adobe Acrobat Reader
Inverters, Inverter/Chargers, Smart Battery Chargers, Emergency
Backup Power, Tripp-Lite, tripplite, tripp lite, exceltech, iota, Outback,
Inverters,Vanner, Sunny Boy, trace, xantrex, AC Inverters and Accessories !
|
|
