Solar Energy Storage 34k Whr
Item no.: Solar-Energy-Storage
Manufactured by IQUPS
Estimated Lead Time: 3-4 Weeks*

U.S.: In Stock
Europe: In Stock
BBS Compatible Caltrans 34KW Hour Energy Storage System - Lithium batteries 48 Volts connected in series. Pack Voltage Nominal 48 VDC; Pack Voltage Peak 60 VDC; Cycle life 3000 Cycles; Five year prorated warranty. Includes Battery Management system, CAN Bus monitoring of temperature and voltage control. Includes programmable master control display.


Nominal Capacity : 34 Kwhr
Battery Type : Lithium Iron Phosphate
Battery Voltage : 48 Volt DC
Operating Voltage: 42 Vdc to 60 Vdc
Cycle Life 3000 Cycles
Charge Voltage: 52.5 Vdc Bulk Charge | 57.0 Vdc Absorption
Charge | 55 Vdc Float Charge
Discharge Voltage: 45 Vdc Max
Max Discharge Current : 500 amps at 80% DOD | 1000 Amps at 50% DOD
Max Charge Current : 700 Amps
Operating Temperature -45 deg C to 65 Deg C
Warranty : 5 Years Prorated
Dimensions : 44.25 X 43 X 34.50 inches ( L X W X H)
34Kwhr Energy Storage System - Lithium batteries 48 Volts connected in series. Pack Voltage Nominal 48 VDC; Pack Voltage Peak 60 VDC; Cycle life 3000 Cycles; Five year prorated warranty. Includes Battery Management system, CAN Bus monitoring of temperature and voltage control.













Since these units are custom made, internal and external distribution of components may vary. Pictures are provided to help visualize the final product, but the final product may vary. We will work with your technical department to provide cutting edge technology with the latest technical components.










Zone Type:To determine the Zone that you are in  Contact us for Information on World Daily Solar Radiation Zones .



Dimensions and Weight
Length: 44.25 in.
Width: 43 in.
Height: 34.50 in.
Shipping Weight: 500 lbs.
